CIRCUITO INTEGRADO LINEAL

Amplifiers, No. of:1
Op Amp Type:High Speed
Gain, Bandwidth -3dB:3.7MHz
Slew rate:9
Termination Type:Through Hole
Package/Case:DIP
Temperature, operating range:-55°C to +125°C
Amplifier IC type:BIMOS
Bandwidth:4.5MHz
Base number:3140
Device marking:CA3140E
IC Generic number:3140
Logic function number:3140
Operational amplifier features:FET Input
Pins, No. of:8
Temp, op. max:125°C
Temp, op. min:-55°C
Voltage, input offset max:15mV
Voltage, supply +nom:15V
Voltage, supply max:36V
Voltage, supply min:4V
